Lorch MicorStick 180 ControlPro, for the workshop (111.7060.0 (PG SA))

—– LORCH 25 YEAR ANNIVERSARY SPECIAL PACKAGE DEAL —–
Including: MicorStick 180 ControlPro AR, Accessories SPA 25 mm², ST 13 mm, WL 3 m, EL 3 m

Everywhere. Convincing. Superior.
Operation concepts: ControlPro, ControlPro RC
10 – 180 A
ED 60% at 40°C: 140 A
Weldable electrode: Up to 4.0 mm Ø

“3 steps and weld” operating concept
Simple one-button operation
Stepless current adjustment
Electrode preselection (basic, rutile, and CEL) for optimal welding parameters
Amperometric digital display
Submenu for individual system setting adjustments

Delivered direct from Lorch (Germany). Delivery schedule is approximately 5-10 working days

◘ Download MicorStick Series Data sheet (EN)
◘ Download MicorStick Series Brochure (EN)

Technical Data & Specifications

Electrode welding
Welding range 115 V:[A] 10 – 140
Welding range 230 V:[A] 10 – 180
Voltage range:[V] 20.4 – 27.2
Weldable electrodes:[Ø in mm] 1.5 – 3.2
Electrode duty cycle
Duty cycle 100% (40°c):[A] 120
Duty cycle 60%:[A] 140
Duty cycle at max. current (40°c):[%] 25
TIG welding
Welding range 1~ 115 V:[A] 5 – 180
Welding range 1~ 230 V:[A] 5 – 200
Voltage range:[V] 10.2 – 18
TIG Duty cycle DC 115 V 230 V
Duty cycle DC 100% (40°c):[A] 130 140
Duty cycle DC 60% (40°c):[A] 150 160
Duty cycle DC at max. current (40°c):[%] 25 25
Process-independent data
Open circuit voltage:[V] 78 – 88
Open circuit voltage VRD:[V] 35 – 35
Mains 115 V 230 V
Mains voltage 1~ (50/60 Hz):[V] 115 230
Mains fuse 1~ (50/60 Hz):[A] 25 16
Positive mains tolerance 1~ (50/60 Hz):[%] 15 15
Negative mains tolerance 1~ (50/60 Hz):[%] 15 15
Mains plug
Mains plug: Schuko
Standards and approvals
Protection class: IP23S
Insulation class: F
Norm/Standard: EN 60974-01
Designation/Certification: CE,S
Cooling type
Cooling type: Gas-cooled
Dimensions length x width x height
Dimensions (LxWxH)[mm] 360 × 130 × 215
Weights
Weight:[kg] 6.2

FOR SPECIALIST PACKAGE REQUIREMENTS PLEASE CONTACT US TO DISCUSS OPTIONS AVAILABLE
